Description
The Ocelot 256 19mm Thermal Monocular is a compact lightweight and ergonomic scope designed for hunters outdoor enthusiasts and tactical professionals who need reliable thermal imaging on the go. Weighing just 14.8 ounces and measuring 182 × 68 × 79mm it’s perfect for easy handling in the field. – Equipped with a high-sensitivity thermal sensor (NETD 25mK) the Ocelot 256 delivers clear imaging even in low-contrast thermal environments ensuring you never miss a target. The variable magnification from 3.2x to 25.6x allows both close-up observation and long-range spotting making it essential for quickly spotting targets monitoring movement and ensuring accurate decisions even when visibility is poor. – Its compact size lightweight design and user-friendly ergonomics make the Ocelot 256 versatile when space is limited. – Thermal Sensor – Type Uncooled VOx(vanadium oxide) – Resolution(pixel) 256*192 – Pixel Size(um) 12*12 – NETD 25mK? 0.025?) – Frame rate(Hz) 50 – Human Detection Distance(m) 900 – Optics – Objective Lens(mm) 19 – Optical Magnification(x) 3.2 – Digital Zoom(x) 2/4/6/8 – Field of View (Horizontal) 9.2° – Field of View (Vertical) 6.9° – Field of View (Diagonal) 11.5° – Focus range 3m-inf – Diopter adjustment(D) -5~5 – Eye Relief(mm) 30 – Display – Type OLED – Resolution(pixel) 1024*768 – Reticle Style 5 – Reticle Color 4(Red/White/Yellow/Green) – Scene Mode City/Rain/Forest – Image Mode WT-HOT/BK-HOT/IN-HOT/RD-HOT/SKY – Photo / Video – Photo resolution(pixel) 1024*768 – Photo Format .JPG – Video Resolution(pixel) 1024*768 – Video Format .mp4 – Image Engine Pard IREA – Main function – PIP Yes – Gyroscope Yes – Loop Recording Yes – E-compass Yes – Storage(GB) Built-in EMMC (32 GB) – Shutter Mechanical shutter – Microphone Yes – Firmware Upgrade Yes – Connections – USB Tpye-C Yes – WiFi Yes – Supported Apps PardVision2 – Power Supply – Battery Type Lithium Ion 18650 – Output Voltage(V) 3.7 – Operating Time(h) 5 – External Power Supply Type-C – Environmental characteristic – Protective Class IP67 – Operating Temp(°C/°F) -30 ~ +55 / -22 ~ +131 – Material – Housing Aluminium Alloy – Objective Lens All-glass multi-coated lens – Measurement – Product Dimension(with LRF L * W * H mm) 180*65*40 – N.W/pcs(with LRF&battery g) 420
